[MIPS] Addressing mode

YEJI ⍢ 2022. 10. 10. 18:57
728x90



Addressing mode에는 여러가지가 존재하는데

MIPS에는 어떤 addressing mode가 있는지 살펴봅시다.





MIPS에 addressing mode는 아래와 같이 있습니다.



① Immediate addressing

② Register addressing

③ Base addressing

④ PC-Relative addressing

⑤  Pseudo-direct addressing





① Immediate addressing

op rs rt imm 16

Ex) addi, andi, slti





② Register addressing

op rs rt rd shamt function

✓  rs, rt, rd가 모두 register를 가리키고 있습니다.

Ex) add, mult, and, slt, sll





③ Base addressing

op rs rt address

Ex) lw, sw





④ PC-Relative addressing

op rs rt offset

Ex) beq, bne







⑤  Pseudo-direct addressing

op offset

Ex) j, jal







◡̈
