[CS] Number of Operands



Three Operands

Add   A, B C

Destination - A

Sources - B and C

(A ← B + C)



Opcode

Oprand #1

Operand #2

Operand #3









Two Operands

Add   A, B

Destination - A

Sources - A and B

(A ← B + C)



Opcode

Operand #1

Operand #2









One Operands

(Assume a special registerm accumulator to hold data value)

ADD   A

 Destination - AC (accumulator)

Sources: A and AC

(AC ← AC + A)



LD   A

(Load store)

Destination - AC

Source - A

(AC ← A)



Opcode

Operand

Temporary store data in AC









Zero operand

(Assume a Stack)

PUSH A

PUSH B

ADD (TOS ← A + B)

POP c (c ← TOS)

TOS - Top of Stack







◡̈
